Solo Chipboard & Woodscrews - PZ - Double Countersunk - Yellow 5.0 x 40mm (200 QTY)

Regular price €6,99
/
Tax included.

A single thread woodscrew mainly used in various types of timber and man-made boards or into masonry with the use of a plastic plug.

• Double countersunk reduces the likelihood of head shear and assists completion of countersinking
• Wax lubricated to enhance screw insertion time, extra driving torque and resistance to corrosion
• 40° deep single thread to provide a secure fixing with high pull-out resistance
• 25° sharp point and single lead for a fast start and improved thread acceptance
• All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length





Head Type Double Countersunk
Lubrication Wax
L (inch) 1 12
Size (mm) 5.0 x 40
MOQ 1
Size (imp.) 10 x 1 12
Material Carbon Steel
Thread L (mm) 35
Substrates Softwood, Chipboard, MDF, Masonry (with plug)
Inner Thread Ø d1 (mm) 3.1
Pack Type Box
Pack Qty 200
Pack Quantity Unit Pieces
Thread Ø (mm) 5
Head Ø (mm) 9.74
Thread Type 40° Single Deep
Corrosion Rating (1-5) 1 - Clean, dry & low humidity environments
Packs per Carton 35
Finish Zinc & Yellow
Driver Bit Size PZ2
MOQ Increment 1
Packs per Pallet 840
L (mm) 40
Gauge 10
Point Type 25° Sharp
Recess Type Pozi
Pallet Qty (pcs) 168000
Feature 5 All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length
Feature 2 Wax lubricated to enhance screw insertion time, extra driving torque and resistance to corrosion
Feature 1 Double countersunk reduces the likelihood of head shear and assists completion of countersinking
Feature 4 25° sharp point and single lead for a fast start and improved thread acceptance
Brand TIMCO
Feature 3 40° deep single thread to provide a secure fixing with high pull-out resistance
Thread Coverage Fully Threaded
Pack Weight (kg) 0.68
Pack Dimensions L x W x H (mm) 98 x 90 x 64
